Starline XM Passthrough Dishwasher

The Starline XM Passthrough Dishwasher is the ultimate solution for fast-paced hospitality environments, delivering powerful performance in a compact footprint. Designed for efficiency and durability, it handles up to 840 dishes per hour with minimal water usage, just 2.2L per cycle. Its 1, 2, and 3-minute cycles offer flexibility for varying service demands, while the hands-free auto-drain and hybrid controls simplify operation. Built with heavy-duty stainless steel components, it ensures long-lasting reliability in commercial kitchens. Perfectly suited for 600mm–700mm bench depths, this dishwasher maximizes space without compromising power.

Features

• Fast Cycle Options: Choose between 1, 2, or 3-minute wash cycles to match your kitchen’s pace and service volume.
• Water-Efficient Operation: Uses only 2.2 liters of water per cycle, reducing utility costs without compromising cleaning power.
• High Capacity Performance: Washes up to 840 dishes per hour, ideal for busy restaurants, hotels, and catering services.
• Rack Compatibility: Supports 450mm racks and includes:
  • 1x 450mm dish rack (600 70081)
  • 1x 450mm cup rack (600 70080)
  • 1x cutlery container (C660503)
• Compact Design: Fits into a 510mm benchgap, suitable for 600mm–700mm bench depths, maximizing space efficiency.
• Advanced Controls: Features Washtech hybrid controls with easy switching to higher power or rapid rinse recovery mode.
• Hands-Free Drainage: Integrated auto-drain system with drain pump for hygienic, hassle-free operation.
• Powerful Wash System: Equipped with a 1.0HP wash pump and dual chemical pumps for thorough cleaning and sanitization.
• Durable Construction: Built with heavy-duty stainless steel wash manifold, scrap trays, and filters for long-term reliability and easy maintenance.

Specification

Hot Water

• Temperature: 65°C
• Connection: 3/4” male, hose supplied
• Pressure: 200-350kPa
• Flow: 20L per minute
• Backflow prevention: Atmospheric vacuum breaker
• Consumption: 2.2L per cycle*

Drainage

• Drain pump flexi-hose: 25mm

Electrical

• Single phase:
  • V: 230-240
  • Hz: 50
  • A/ph: 15
  • Max kW: 3.75
• Single phase:
  • V: 230-240
  • Hz: 50
  • A/ph: 25
  • Max kW: 5.75
• Three phase:
  • V: 400-415
  • Hz: 50
  • A/ph: 15
  • Max kW: 9.00

Dimensions

• Width: 655mm
• Depth: 660mm
• Height: 1530mm

Water Quality

• pH: min-7  max-8
• Hardness: min-20 max-100
