Waldorf RN8203E-B 300mm Electric Cooktop Bench Mount

The Waldorf RN8203E-B 300mm Electric Cooktop Bench Mount is a compact, high-performance cooking solution designed for demanding hospitality environments. Built with heavy-duty materials and a stainless steel exterior, this unit offers powerful 2.4 kW open radiant elements and optional hot plate or griddle configurations. Its modular design allows seamless integration into commercial kitchens, while easy-clean features and front-access servicing ensure minimal downtime. Ideal for restaurants, hotels, and catering operations, this cooktop delivers reliable performance and flexibility in a space-saving format.

If you would like to view this cooktop, please contact us at 0800 503 335 or [email protected].

Waldorf RN8203E-B 300mm Electric Cooktop Bench Mount - Product Features

• Heavy-Duty Construction: Welded hob with 1.5 mm 304 stainless steel bull nose and aluminized steel internal structure.
• Cooking Options: Includes 2.4 kW open radiant elements; optional hot plate and 12 mm thick griddle plate available.
• Modular Design: Fully modular with low-back (RNL) models available for flexible kitchen layouts.
• Easy Maintenance: Removable vitreous enamelled element modules and spill trays; hinge-up sections for quick access.
• User-Friendly Controls: Large heat-resistant knobs with clear settings, energy regulators, and indicator lights.
• Bench Mount Configuration: Supplied with four adjustable stainless steel legs (80 mm–105 mm height) for stable installation.

Features

• Cooktop
  •  Welded hob with 1.5mm 304 stainless steel bull nose
  • Splashback and side panels 1.2mm 304 stainless steel
  • Splashback and side panels 1.2mm 304 stainless steel
  • Front panels 0.9mm 304 stainless steel
  • 2.4kW open radiant elements in heavy-duty welded element frames
  • Vitreous enamelled element module and hob spill  trays
  • Hot Plate elements with machine finished 8mm steel plate
    (optional extra)
  • 12mm thick mild steel griddle plates
  • 2.5mm 304 stainless steel griddle splash guards
  • Aluminised steel internal construction

• Bench Mount

  • Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs with adjustable feet.
  • Adjustable height 80mm – 105mm

• Controls
  • Large easy use control knob - heat resistant reinforced
  • Easy view control settings on knob
  • Radiant elements with energy regulator controls
  • Hot Plate elements with energy regulator controls
  • 50-320˚C    thermostat    per    300mm    griddle    section
  • Indicator lights for power and heating for each element control

• Cleaning and Servicing
  • All models with easy clean stainless steel external finish
  • Removable vitreous enamelled element module and hob spill trays
  • Hinge up element and griddle sections
  • Access to all parts from front of unit

Specifications

• Cooktop

  • 2.4 kW Open Radiant elements
  • 2.0 kW Hot Plate elements
  • 3.6 kW Griddle elements
  • (per 300mm griddle section)
• Griddle Plate

  • 300mm Griddle cooking surface
  • 292mm x 475mm, 1387cm2
• Electrical requirements

  • RN8203E
  • 3.6 kW, 230-240Vac, 50/60hz, 1P+N+E, 15A
• Electrical connection
  • 130mm from RH side, 31mm from rear, and 85mm from bench

• Dimensions

  • Width: 300mm
  • Depth: 805mm
  • Height: 315mm
  • Incl. splashback: 530mm
  • Incl. low back: 370mm
• Net weight

  • 32kg
• Packing Data
  • 0.20m3, 55kg
  • Width: 870mm
  • Depth: 350mm
  • Height: 665mm
