Blue Seal Evolution IN54R5F Induction Range Convection Oven

The Blue Seal Evolution Series IN54R5F is a top-tier induction-range convection oven designed for the demands of professional and hospitality cooking environments. This model features two round induction zones and two full-area induction zones, delivering flexibility and power to accommodate various cooking needs. Ideal for restaurants, hotels, and catering businesses, this induction combines high performance with durability, fitting seamlessly into your kitchen.

This induction range convection oven is designed with the professional chef in mind, featuring heavy-duty stainless-steel legs with two adjustable feet at the front and two rear rollers, making it fully modular and easy to install, clean, and use. Its strong galvanised steel, a vitreous enamelled control panel, and a drop-down door ensure long-lasting use and ease of maintenance. The electric convection oven is also equipped with dual circulation fans and thermostatic control, which guarantees consistent and precise cooking and baking results.

Features

Induction Cooktop: This induction cooktop features two types of induction zones: two 5.0kW round area induction zones and two 5.0kW full area induction zones. It also has a 6 mm-thick ceramic glass surface, ensuring quick and precise heating. Energy efficiency is optimised with automatic pan detection.

Convection Oven: The oven includes two fans and a thermostat adjustable from 50°C to 320°C, providing even heat distribution for versatile cooking and baking. It features 6.1 kW of heating elements for consistent performance.

Durable Construction: Built with a fully welded, vitreous enamelled liner and a heavy-duty stainless-steel exterior, along with a galvanised steel chassis, this appliance is both durable and easy to clean.

Dimensions and Capacity: Measuring 900mm in width, 812mm in depth, and 1085mm in height, this unit is designed to fit seamlessly into any commercial kitchen.

Flexibility: With a GN 2/1 capacity and 5-position racking, this appliance can handle a wide variety of dishes. It also includes removable wire racks and an enamel-coated spill tray for easy maintenance.

Mobility and Installation: For easy movement, the appliance has 63mm-diameter heavy-duty stainless-steel legs with two adjustable front feet.

Overall Construction

• Galvanized steel chassis
• Welded hob with 2.0mm 304 stainless steel top
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• Vitreous enamelled control panel
• 63mm dia. heavy-duty 1.2mm 304 stainless steel adjustable legs at front and two rollers at rear

Cooktop

• Two 6mm thick ceramic glass 375mm x 650mm each
• Induction air cooling with front access air filter
• Fan cooled induction cooktop oven heat protection with front exhaust

Oven

• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 5 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Vitreous enamelled removable oven spill tray
• 6.0kW heating elements
• 2 fan motors
• Drop down door
• 0.9mm 304 stainless steel door outer
• 1.0mm vitreous enamelled door inner
• 38mm high density fibreglass insulated
• Supplied with two chrome wire oven racks

Induction Cooktop Controls

• Variable power controls for each induction zone
• Heating ON indicator lights with pan detection indication
• Error mode indicator

Oven Controls

• 50-320°C thermostatic control
• Indicator lights for power and heating
• Oven fans and heating automatic off when door open

Cleaning and Servicing

• All models with easy clean stainless steel external finish
• Fully sealed cooking surface
• Removable for cleaning cooling air filter
• Removable for cleaning exhaust screen
• Removable oven racking and spill tray
• Easy clean vitreous enamel oven and door inner
• Access to all service parts from front of unit

Specifications

Cooktop

• 2 x 5.0kW Ø 270mm Round Induction (LH)
• 2 x 5.0kW Full Area Induction zones (RH)

Oven

• 2 x 2kW oven fan elements
• 1 x 2kW oven bottom element
• 2 x oven circulation fan motors

Oven Dimension

• Width 665mm
• Depth 560mm
• Height 350mm
• Rack size 655mm x 530mm
• Rack positions 5

Electrical requirements

• 26.1kW, 400-415V, 50/60Hz, 3P+N+E
• 36.3A / phase

Electrical connection

• 130mm from RH side, 32mm from rear, and 318mm from floor

Dimensions

• Width 900mm
• Depth 812mm
• Height 915mm
• Incl. splashback 1085mm
