Blue Seal Evolution IN54R5 Induction Range Convection Oven

The Blue Seal Evolution Series IN54R5 is the perfect induction-range convection oven made for demanding professional environments. This model features four high-powered round induction zones and an electric convection oven, making it perfect for high-volume cooking in restaurants, hotels, and catering businesses. This oven is designed to fit perfectly into your kitchen layout, offering a flexible cooking solution.

The dual oven circulation fans and thermostatic control are adjustable, ensuring perfect and consistent cooking results, and the five-position racking provides ample space for large-scale culinary operations, perfect for cooking and baking your best-selling menus. This induction-range convection oven features heavy-duty stainless-steel legs with two adjustable feet at the front and two rollers at the rear, ensuring stability and ease of movement. The fully modular design makes it easy to install, clean, and service, helping you maintain a high standard of kitchen hygiene.

Features

Induction Cooktop: This round induction cooktop features four 5.0kW full-area induction zones with a 6mm thick ceramic glass surface, ensuring quick and precise heating. Energy efficiency, optimised with automatic pan detection.

Convection Oven: The oven comes with two fans and a thermostat adjustable between 50°C and 320°C, providing even heat distribution for versatile cooking methods. It includes 6.1 kW heating elements for reliable cooking and baking performance.

Durable Construction: Constructed with a fully welded, vitreous enamelled liner and a heavy-duty stainless-steel exterior, along with a galvanized steel chassis, this appliance is designed for durability and easy cleaning.

Dimensions and Capacity: With dimensions of 900mm width, 812mm depth, and 1085mm height, this unit fits perfectly into any commercial kitchen.

Flexibility: Featuring a GN 2/1 capacity and 5-position racking, this appliance can accommodate a wide range of dishes. It includes removable wire racks and an enamel-coated spill tray for easy maintenance.

Mobility and Installation: Designed for easy mobility, the appliance has 63mm-diameter heavy-duty stainless-steel legs with two adjustable front feet and two rear rollers. Its fully modular design ensures straightforward installation and servicing.

Overall Construction

• Galvanized steel chassis
• Welded hob with 2.0mm 304 stainless steel top
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• Vitreous enamelled control panel
• 63mm dia. heavy-duty 1.2mm 304 stainless steel adjustable legs at front and two rollers at rear

Cooktop

• Two 6mm thick ceramic glass 375mm x 650mm each
• Induction air cooling with front access air filter
• Fan cooled induction cooktop oven heat protection with front exhaust

Oven

• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 5 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Vitreous enamelled removable oven spill tray
• 6.0kW heating elements
• 2 fan motors
• Drop down door
• 0.9mm 304 stainless steel door outer
• 1.0mm vitreous enamelled door inner
• 38mm high density fibreglass insulated
• Supplied with two chrome wire oven racks

Induction Cooktop Controls

• Variable power controls for each induction zone
• Heating ON indicator lights with pan detection indication
• Error mode indicator

Oven Controls

• 50-320°C thermostatic control
• Indicator lights for power and heating
• Oven fans and heating automatic off when door open

Cleaning and Servicing

• All models with easy clean stainless steel external finish
• Fully sealed cooking surface
• Removable for cleaning cooling air filter
• Removable for cleaning exhaust screen
• Removable oven racking and spill tray
• Easy clean vitreous enamel oven and door inner
• Access to all service parts from front of unit

Specifications

Cooktop

• 4 x 5.0kW Ø 270mm Round Induction zones

Oven

• 2 x 2kW oven fan elements
• 1 x 2kW oven bottom element
• 2 x oven circulation fan motors

Oven Dimension

• Width 665mm
• Depth 560mm
• Height 350mm
• Rack size 655mm x 530mm
• Rack positions 5

Electrical requirements

• 26.1kW, 400-415V, 50/60Hz, 3P+N+E
• 36.3A / phase

Electrical connection

• 130mm from RH side, 32mm from rear, and 318mm from floor

Dimensions

• Width 900mm
• Depth 812mm
• Height 915mm
• Incl. splashback 1085mm
